TD75 SERIES BELT CONVEYOR

According to the difference of its supporting frame structure, TD75 series belt conveyor has two models: mobile and stable. Based on the belt material, it can be divided into rubber belt, plastic belt and steel core belt. The working temperature should be between -10℃--+40℃, and the temperature of the material should be below 70℃, but the heat resistant rubber belt can transport material that the temperature is below 120℃。When the material temperature is much higher, then rubber belt is not a good choice. When transporting acidic, alkaline oily materials and organic solvent materials, oil-resistant and acidic & alkaline resistant rubber plastic belt should be adopted. The width range of TD75 belt conveyor is between 500mm and 2400mm. Users can determine the layout, width, number of rubber layers and belt thickness by calculating material type, weight, length, etc.

TECHNICAL SUPERIORITY

Driving part: The driving device consists of driving frame, motor, high speed coupling, reducer, reducing coupling. It is divided into left assembling and right assembling according to the layout requirement.
Rotating part: It has two main categories: driving roll and direction reversion.
Roll part: It consists of groove, parallel, regulating and buffer rolls.
Clearing part: Including spring cleaner and nonleaded cleaner.
Discharging part: Including stationary plough discharger and electrical discharger.
Braking part: Belt type non-return device and roller non-return device.
Accessories: Cover, guiding chute and funnel.

SPECIFICATION

Width (mm)	Speed (m/s)
	0.8	1.0	1.25	1.6	2.0	2.5	3.15	4.0	4.5	5.0	5.6	6.5
	Q(m³/s)
500	69	87	108	139	174	217
650	127	159	198	254	318	397
800	198	248	310	397	496	620	781
1000	324	405	507	649	811	1014	1278	1622
1200		593	742	951	1188	1486	1872	2377	2674	2971
1400		825	1032	1321	1652	2065	2602	3304	3718	4130
1600					2186	2733	3444	4373	4920	5466	6122
1800					2795	3494	4403	5591	6291	6989	7829	9083
2000					3470	4338	5466	6941	7808	8676	9717	11277
2200							6843	8690	9776	10863	12166	14120
2400							8289	10526	11842	13158	14737	17104
